Model | AT.R6M00.515 | AT.R6M00.516 |
CPU Types | Intel® Xeon® Quad-Core X3450 (2.66 GHz) | Intel® Xeon® Quad-Core X3450 (2.66 GHz) |
CPU max. support | 1 | 1 |
CPU Cache | 8M L3 Cache | 8M L3 Cache |
Memory | 2GB (1x2GB) | 2GB (1x2GB) |
Memory max. support | ECC DDR3 1333MHz Registered | ECC DDR3 1333MHz Registered |
| Up to 48 GB Max (6 DIMM slot) | Up to 48 GB Max (6 DIMM slot) |
Graphics | Embedded graphics controller with 32MB video memory | Embedded graphics controller with 32MB video memory |
PCI Slots | 1x PCI Express® x16 slot | 1x PCI Express® x16 slot |
| 2x PCI Express® x8 slot | 2x PCI Express® x8 slot |
| 1x PCI Express® x4 slot | 1x PCI Express® x4 slot |
(Total#, #, x xbit/xxxM H z) | 1x 32-bit,3.3V PCI slots | 1x 32-bit,3.3V PCI slots |
Harddisk | 1x 500GB 3.5" Enterprise SATA 7200 RPM | 1x 300GB 3.5" SAS 15K RPM |
Std. HDD Controller | Integrated six-port SATA S/W RAID 0,1,5*,10 | Integrated six-port SATA S/W RAID 0,1,5*,10 |
H /W RAID Controller | - | H /W RAID 0/1/10/5 |
Max.# Internal Disks supports | 4 x 3.5" Hot Plug bays for SAS,SATA HDD | 4 x 3.5" Hot Plug bays for SAS,SATA HDD |
Optical device | DVDRW | DVDRW |
Onboard Gigabit Ethernet | Yes, Dual | Yes, Dual |
Redundant Power Supply | No | No |
Form Factor | Tower/4U rack mountable | Tower/4U rack mountable |
OS Support | Windows Server 2008 (x86/EM 64T) | Windows Server 2008 (x86/EM 64T ) |
| Windows Server 2008 R2 (EM 64T ) | Windows Server 2008 R2 (EM 64T ) |
| Windows Server 2003 Enterprise Edition | Windows Server 2003 Enterprise Edition |
| Red Hat Enterprise Linux 5.4 (x86/EM64T) | Red Hat Enterprise Linux 5.4 (x86/EM64T) |
| SuSE Linux Enterprise Server 11 (x86/E M 64T) | SuSE Linux E terprise Server 11 (x86/EM 64T) |
| VMWare ESX 4 | VMWare ESX 4 |
| VMWare ESXi 4 Installable | VMWare ESXi 4 Installable |
| VMWare ESXi 4 Embedded | VMWare ESXi 4 Embedded |
Warranty | 3 Yrs warranty Part & Labor, 5x8, Onsite Sevice NBD Thailand | 3 Yrs warranty Part & Labor, 5x8, O nsite Sev ice NBD Thailand |
Promotion for End User | Acer Smart Console (KVM over IP ) | Acer Smart Console (KVM over IP ) |
| Acer Smart Server Manager (S /W Management) | Acer Smart Server Manager (S /W Management) |
| | |
