Model | AT.R5300.510 | AT.R5300.511 |
CPU Types | Intel® Xeon® DP S ix-Core E 5645 (2.4 Hz, 5.86 GT/sQPI) | Intel® Xeon® DP Six-Core X5675 (3.06GHz, 6.40 GT/sQPI) |
CPU max. support | 2 | 2 |
CPU Cache | 12MB L3 Cache | 12MB L3 Cache |
Memory | 4GB (2x2GB) | 4GB (2x 2GB) |
Memory max. support | ECC DDR3 1333MHz Registered | ECC DDR3 1333MHz Registered |
| Up to 192 G B Max (18 DIMM slot) | Up to 192 GB Max (18 DIMM slot) |
Graphics | Embedded graphics controller with 16 MB video memory | Embedded graphics controller with 16 MB video memory |
PCI Slots | 6 x PCI Express® 2.0 x8 slots | 6 x PCI Express® 2.0 x8 slots |
| 1 x Flex I/O (PC I-E 2.0 x8) | 1 x Flex I/O (PC I-E 2.0 x8) |
(Total#,#, xxbit/xxxM H z) | 2 x PC I-X 64/133MHZ and 1 x PCI Express® 2.0 x8 | 2 x PC I-X 64/133MHZ and 1 x PC I Express® 2.0 x8 |
| (Optional) | (Optional) |
Harddisk | 2 x500GB 3.5" Enterprise SATA 7200 RPM | 2 x 1TB 3.5" Enterprise SATA 7200 RPM |
Std. HDD Controller | Integrated six-port S A T A S /W RAID 0,1,5*,10 | Integrated six-port SATA S/W RAID 0,1,5*,10 |
H /W RAID Contr oller | Integrated SAS H/W RAID with cache memory 512MB, | Integrated SASH /WRAID with cache memory 512MB, |
| RAID level 0/1/10/5/50/6/60 | RAID level 0/1/10/5/50/6/60 |
Max. # Internal Disks supports | 6 x 3.5" Hot Plug bay s for SATA/SAS HDD | 6 x 3.5" HotPlug bays for SATA /SASHDD |
Optical device | DVDRW (Slim-type) | DVDRW (Slim-type) |
Onboard Gigabit Ethernet | Yes, Quad | Yes, Quad |
Redundant Power Supply | 1+1 hot-swappable, redundant power supply (optional) | 1+1 hot-swappable, redundant power supply (optional) |
Form Factor | 2U rack-optimized | 2U rack-optimized |
Sliding Rail Kit | Free Bundled!! | Free Bundled!! |
OS Support | Window s Server 2008 (x86/EM 64T ) | Window s Server 2008 (x86/EM 64T ) |
| Window s Server 2008 R2 (EM 64T ) | Window s Server 2008 R2 (EM 64T ) |
| Window s Server 2003 Enterprise Edition | Window s Server 2003 Enterprise Edition |
| Red Hat Enterprise Linux 5.4 (x86/EM64T) | Red Hat Enterprise Linux 5.4 (x86/EM64T) |
| SuSE Linux Enterprise Server 11 (x86/EM64T) | SuSE Linux Enterprise Server 11 (x86/EM64T) |
| VMWare ESX 4 / VMWare ESXi 4 Installable | VMWare ESX 4 / VMWare ESXi 4 Installable |
| VMWare ESXi 4 Embedded | VMWare ESXi 4 Embedded |
Warranty | 3 Year warranty Part & Labor, 5x8, | 3 Year warranty Part & Labor, 5x8, |
| Onsite Service NBD Thailand | Onsite Service NBD Thailand |
| | |
