Specifications

CPU Type

Intelฎ  Xeonฎ  Processor 5600 (Option)

Mainboard

Chipset: Intelฎ 5500+ICH10R

Number of processor support

2

System Bus Speed

QPI 4.8/5.86/6.4 GT/s

Slot Type

1x Half-Length PCI 32 bit/33M Hz

3x PC -Express 2.0 x4 (x8 Mechanical)

1x PCI 32 bit/33M Hz

2x Half-Length PCI Express 2.0x8

Memory Capacity

Up to 32GB DDR3 EC C  Registered With Parity /

UDIMM (8 DIMMs)

Integrated ATA

-

Integrated Serial ATA

6x SATA II with Support for RAID 0, 1, 10

Integrated LAN

2x G igabit E thernet connections

Integrated Graphics

8 MB

Server Management Support

Intelฎ System Management Software

Intergrated Audio

-

Chassis

Intel: Tower

Drive Bays

Up to 6 fixed drive , (Optional 6 Hotswap Drive )

 3x5.25 bays

USB Connector

2 Front , 4 Rear

Power Supply

600 watt (1+0) Option : Power Redundent

Memory

Option

Kingston Memory  DDR3 ECC

Harddisk

Option

 Up to 4 drive

Floppy Drive

Option

Optical Drive

Option

Warranty

3 Years warranty Part

Intel Multi-Core Xeon Processor

Price

BX80614E 5606 (2.13G H z/8M B/4Cores/H T)

7,200

BX80614E 5620 (2.40 G Hz/12M B/4Cores/H T)

12,100

BX80614E 5645 (2.40 G Hz/12M B/6Cores/H T)

17,500

BX80614X5650 (2.66 G H z/12M B/6 ores/HT )

31,000

BXS TS 100A (Intel thermal heat sink)

700

Kingston Memory

KVR1333D3E9S/4G (ECC  DDR3   Dimm  4GB)

1,250

Seagate Harddisk

ST500NM0011 (500GB  Enterprise)

ST31000524NS (1 TB  Enterprise)

5,200

ST32000644NS (2 TB Enterprise)

9,700

Intel Accessories

Intel 6 bay Hotswap Backplane (Hot Swap KIT)

4,400

Rack Kit for convert to Rack 5.2U

4,500

Adaptec Controller

ASR-2405-KIT ( Adaptec 4-ch RAID  0,1)

8,250

ASR-6405-KIT (Aaptec 4 ch RAID  0,1,5)

13,500
